JDC-20T-002/JDC-20Z-002 board to board connector

JDC-20Z-002 & JDC-20T-002

DC-20Z-002 and JDC-20T-002 represent state-of-the-art electronic control modules designed for precision and adaptability in industrial automation. These modules offer a wide range of customizable functions, catering to a variety of applications in manufacturing, robotics, and machinery automation. Known for their robust construction and high-performance capabilities, JDC-20Z-002 and JDC-20T-002 provide reliable and efficient control solutions for complex industrial processes, ensuring increased productivity and operational reliability.

Online Inquiry

JDC series 20 pin rectangular female male power modular connector

Product Information

Product model		JDC-20Z-002 Female Connector JDC-20T-002 Male Connector
Mechanical Life		1000 times
Insulation Resisitance		≥1000MΩ
Housing Material		PET UL94V-0 Black
Contact	Spec	Signal contact 20#	Power contact 8#
	Contact Quantity	16	4
	Rated Current/Rated Volatage	5A/120V AC	75A/600V AC
	Contact Resistance	≤5.0mΩ	≤1.0mΩ
	Withstand Voltage	1000V AC	1500V
	Surface Finish	Gold plated over nickel	Silver plated over nickel
	Terminal Style	Crinmping (Y),PCB Tail(B),Solder Cup (H)
	Material	Pin,Jack	Brass or copper alloy
		Crown Spring	Beryllium bronze
Working Temperature		-40℃ ~ +125℃

Product Applications

1. Intelligence high frequency switching power supply, communication power supply, electric power,railway power supply,LED power.
2. UPS systems
3. Contravariant power
4. Drawer low-voltage cabinet etc.
