Interface size and product performance fully meet the national standard GB / T20234-2015 requirements and requirements Temperature detection device using temperature sensor or temperature switch for customer choice, to meet the different customers S
Interface size and product performance fully meet the national standard GB / T20234-2015 requirements and requirements
Temperature detection device using temperature sensor or temperature switch for customer choice, to meet the different customers
Superior protection performance, with the protection device is connected, the protection of the power plug is higher than the IP55 (working state)
|
Spec |
9 pin 250A/200A/125A/80A |
|
Operating Temperature |
-30～+50oC |
|
Protection grade |
IP55 |
|
Mechanical Life |
10000 times |
|
Insertion force |
<140N |
|
Housing Material |
UL94V-0 |
|
Voltage rating |
750V DC |
|
Rated Current |
250A/200A/125A/80A |
|
Contact Resistance |
≤0.5mΩ |
|
Insulation impedance |
≥2500MΩ DC1000V |
|
Withstand Voltage |
DC+、DC-、PE≥3500V; S+、S-、CC1、CC2、A+、A-≥1500V. |
