Housing Material

.UL94V-0,(Thermoplastic high temperature plastic , UL94V-0 black)

Contact

     Spec.

(4 pins contact)

 Voltage rating

450V AC

Rated Current

80A

Contact Resistance

≤0.75mΩ

Insulation impedance

≥ 5000MΩ（DC500V）

  Withstand  Voltage

1500V

   Retention

4.5N Min/Pin

 Surface Finish

The contact area is plated with gold, the welding area is tin plated, and the bottom is nickel plated.

Terminal  Style

Welding type

 Material

 High performance copper alloy / imported high conductivity copper alloy.
