Product Name Female,Vertical,12 Pin~72Pin (CY8-2.54-12(12)ZSWBJ Power blade connetor blade power connector powerblade connector healthy connector mass health connector wire connector ma health connector battery terminal connector MDL card Edge connectors are generally used for connecting one PCB to another, the edge connector is plugged in to a socket on another PCB thus making the connection. Examples of this can be seen on a computer motherboard where you plug a graphics card with a gold edge connector into the socket on the mother board. The surface finish of edge connectors is usually with what is known as Hard Gold on top of nickel, this allows for the repeated plugging and unplugging of the connector. To help guide the edge connector into the socket they need to have a bevelled leading edge.
Selected by customer
Quantity of Pin hole in the housing is 6-36 PIN at A row & B row, Customer could choose the number and the position of contacts,A&B row has 6-36 Pins from left to right, The distance between two rows contact tail is 5.08mm
Contact Pitch is 2.54mm, contact tail: through hole, mating with 1.60±0.20mm thickness PCB gold finger, used in the PCB connection of communications equipment, precision instrument，computer etc.
Operating Temperature ：-55℃~+125℃（Include 40℃ temperature rise）
Relative Humidity ：40℃，90-95%
Air pressure ：40KPa
Shock： Acceleration300m/ s²
Mian Technical Parameters
Voltage Rating ：300V AC
Mechanical Life：500 times
Insertion Force Per Pin ≤2N withdraw force Per PIN≥1.2N
Part Number System
